#32

F15-07090017 - Swing link spring - F15

Parsun F15-07090017 Swing link spring

Part Number: F15-07090017 (PAF15-07090017)
The part is used for engine models: Parsun F9.9/F15

Price: 12,05 €
In stock and ready for immediate dispatch from our warehouse in Sweden.

No Image Available

This torsion spring applies spring force to the enrichment-valve linkage on the Parsun F15 carburetor.

It sits at the valve swing lever and is a different component from the throttle-linkage spring.

Exploded Diagrams & Assemblies Containing F15-07090017

Parsun F15
- Carburetor
